AUO-ARO
The AUO-ARO jet fans provide efficient day-to-day ventilation and dependable smoke control performance in enclosed car parks.
Their aesthetic oval design with long silencers and fan based on the robust NovAx platform ensure exceptionally low sound levels and high thrust, while meeting the strict requirements for certified smoke exhaust operation, offering both performance and safety.
-
Above ErP compliance
NOVENCO fans surpass the EU Ecodesign (ErP) requirements and deliver higher efficiency with consistent performance. This results in lower power use, reduced operating costs, and a more sustainable choice for modern ventilation systems.
-
EN 12101-3:2015 certified
NOVENCO smoke fans are tested and certified for operation with variable speed drives for temperatures at up to 400°C during 2 hours according to EN 12101-3 for powered smoke and heat control fans.
-
Reversible and unidirectional models
ARO models offer full reversible airflow, while AUO models provide robust unidirectional ventilation for standard and smoke control operation.
-
High thrust with low noise
Thrust ranges from 5 to 111 N with exceptionally sound pressures between 35 and 64 dB(A) at only 3m from the jet fan, supported by oval silencers and NovAx fan technology.
-
Certified smoke extract performance
Approved for F200, F300 and F400 smoke extract operation, ensuring reliable performance in emergency conditions.
Above ErP compliance
NOVENCO fans surpass the EU Ecodesign (ErP) requirements and deliver higher efficiency with consistent performance. This results in lower power use, reduced operating costs, and a more sustainable choice for modern ventilation systems.
EN 12101-3:2015 certified
NOVENCO smoke fans are tested and certified for operation with variable speed drives for temperatures at up to 400°C during 2 hours according to EN 12101-3 for powered smoke and heat control fans.
The AUO-ARO jet fans are designed for car park installation. They feature three impeller diameters of Ø290, Ø380 or Ø500 mm and operate within a standard temperature range of –20 to +40°C. Two-speed motors are standard.
Materials include a galvanised steel fan casing, galvanised steel hub, aluminium blades, and deflectors on the outlets. Reversible models have deflectors on each side of the jet fan.
- F200, F300 and F400 smoke extract approvals in accordance with EN 12101-3:2015.
- All smoke fans have been tested at high temperature for at least 2 hours.
Thrust levels from 5 to 111 N and sound pressures from 35 to 64 dB(A) at 3m/45°.
Three jet fan sizes (290, 380 and 500) with two-speed motors as standard.
- Galvanised steel casings, silencers and hub with aluminium impeller blades.
- Corrosion category C3 (EN-ISO 12944-2:2017).
- Reversible (ARO) and unidirectional (AUO) versions.
- Deflectors on the outlets (on both sides for reversible ARO).
- Inlet wire guard for the unidirectional AUO.
Impeller diameters: Ø290, Ø380 and Ø500 mm with measured thrust up to 111 Newtons (N).
